CENTRAFLEX CONTINUOUS HINGE

AL03349 – CENTRAFLEX Continuous hinge and seal.

Perfect for hinging and sealing doors on trailers and larger tool boxes.

Centraflex is a stylish, one piece, and continuous hinge developed by taking full advantage of the latest advances in new materials and manufacturing technology.

The membrane of the Centraflex Hinge is a flexible resin comprising of a patented blend of polyester elastomers combining the high strength of engineering resins with excellent flexibility. The result is that Centraflex Hinge has an excellent flex-life at temperatures ranging from minus 40 deg C to 50 deg C.

During the manufacturing process; co-extruded rigid P.V.C profiles are fused together with the molten, Centraflex Hinge membrane creating an extremely strong and resilient hinge.  For example a 1 metre length fitted horizontally has a S.W.L of 100 kg.

Centraflex is a well-designed hinge offering many advantages over conventional continuous hinges currently available in the market.

Features:

– Durable. Tested to over 50,000 operating cycles.

– Secure interlocking profile when closed.

– Maintenance free.

– Aesthetically pleasing, low exterior profile.

– Concealed fixings.

– Easy to fix.

– Weatherproof continuous seal.

– Corrosion resistant.

– UV light stabilised.

– Excellent flex life.

– Competitively priced.
