A300

The A300 gearbox is  designed for Agricultural applications with high HP requirements.

Featuring a sturdy SG iron housing & high quality materials.

Average dry weight = 110 Kg.

Shaft size = 1 ¾ Z20 spline. (1000 rpm PTO)

Input shaft = Z

HP ratings vary with gear ratio and  input speed.  (540 or 1000 rpm.)

Oil capacity = 6.0 lt (approx.) – SAE 90 EP gear oil.
